Ürün ayrıntıları:
Ödeme & teslimat koşulları:
|
| Ürün adı: | Havalı Diyafram Pompası | Maks. Kendinden emişli Asansör (kuru): | 5,3 |
|---|---|---|---|
| Maks. Parçacık çapı: | 9mm | Maks. Hava basıncı: | 8.3bar |
| Max. Akış: | 903lpm | Ağırlık: | 95kgs |
| Vurgulamak: | hava tahrikli diyafram pompası,2 inç hava diyafram pompası |
||
Kauçuk Havalı Diyafram Pompası 3 İnç Korozyon Direnci
Kauçuk, termoplastik veya teflondiaframın pistonlu hareketinin ve diyaframın her iki tarafındaki uygun valflerin karşılıklı hareketinin bir kombinasyonunu kullanan Hava diyafram pompası ( Membran pompası, hava ile çalışan çift diyaframlı pompa (AOOD) veya pnömatik diyafram pompası olarak da bilinir) bir sıvıyı pompalamak için kelebek vanalar, kapak vanaları veya diğer herhangi bir kapatma vanaları).
Havalı Diyafram Pompası Tanımı:
Hava girişi | 1 / 4-18NPTF-1 |
Sıvı çıkışı | 1-11-1 / 2NPTF-1, Rp1-11BSP |
Sıvı Girişi | 1-11-1 / 2NPTF-1, Rp1-11BSP |
Maks. Akış | 1903L / dk |
Maks. kafa | 70M |
Maks. Kendinden emişli Asansör (kuru) | 9m |
Maks. Hava basıncı | 8.3bar |
Maks. Parçacık çapı | 9mm |
Maks. Kurulum boyutu | 542 x 245 x 679mm |
Ağırlık | 95kg |
Gürültü @ 70psi | <70 db |
Havayla Çalışan Diyafram Pompası Teknik Özellikleri
Hava Diyafram Pompası
1. Sızdırmaz
2. İyi kendinden emişli performans
3. Orta her türlü iletmek
4. Malzeme: Dökme çelik, Alu, SS, PP
A 80 XX - XXX - X (model seçimi)
Boru ağzı şekli: A-BSP B-NPT (F) C-Flanş
Diyafram malzemesi: 9 - Santopren H - Hytrel T - PTFE / Santopren
Top malzemesi: 9 -Santopren H - Hytre T - PTFE A - Asetal
Top koltuk malzemesi: P / K - Polipropilen / Kynoar SS - Paslanmaz Çelik
Pompa malzemesi: SS - Paslanmaz Çelik AL - Alüminyum Alaşımlı CI - Karbon Çelik P / K - Polipropilen / Kynoar
Özellikleri
1. Pompamız doğrudan dalgıç bir pompa olarak kullanılabilir, güç kaynağı olarak hava kullanır ve sızıntı ve diğer güvenlik riskleri yoktur. Bu diyaframlı pompanın, motorun bakımı nedeniyle oluşan dalgıç pompadan daha düşük maliyeti vardır.
2. Pompalar, duraksız, buzsuz çalışma sağlar.
3. Cıvata bağlantı tasarımı optimum performans için eşit sızdırmazlık basıncı sağlar.
4. Diyafram, top ve top koltuk uzun ömürlü ithal malzemeler benimsemek.
5. Pnömatik motorları nedeniyle potansiyel olarak patlayıcı alanlarda kullanılabilirler.
6. Parçacıklar ve yüksek viskoziteli aşındırıcı, uçucu, yanıcı, zehirli sıvıları pompalayabilir.
Uygulanan Maksimum Sıcaklık Limitleri (diyafram / bilye / conta malzemesi)
Asetal ································· 40 ° 40 ° A - 150 ° F (4.4 - 65.5 ° C)
Santoprene ················································· ········································· -40 ° - 225 ° F (-40 °) - 107.2 ° C) Teflon ········································································· ······························································ ···· 40 ° - 220 ° F (4.4 ° - 104 ° C) Nitril ·················································· ······························································ ···················· 10 ° - 180 ° F (-12 ° - 82 ° C) Viton ····· 10 ° - 180 ° F (-12 ° - 82 ° C) Viton ················ ······························································ ································· -40 ° - 350 ° F (-40 ° -176.6 ° C) Hytrel · ·· ··································· ······························································ ············ -20 ° -150 ° F (-12 ° - 93 ° C) Kynar ······································· ······························································ ························ 10 ° -200 ° F (-28.9 ° - 65.5 ° C), polipropilen ·········· ······························································ ································· 32 32 - 175 ° F (0-79,4 ° C)
3 "Akış diyagramı
İlgili kişi: Mr. ALLSON
Tel: 008618122100289
