Ürün ayrıntıları:
Ödeme & teslimat koşulları:
|
| Ürün adı: | Havalı Diyafram Pompası | Ana uygulamalar:: | Yağ, su, kimyasal, vb |
|---|---|---|---|
| Sürücü:: | Hava işletilen | Maks. kafa: | 70M |
| Çalışma hava basıncı: | 0.10-0.83Mpa | Maksimum Akış Hızı: | 667lpm |
| Parçacık Boyutu: | 7mm | Kuru Emme: | 6.2m |
| Gürültü Seviyesi @ 70psi: | 75dB | Ağırlık: | 24.5KGS |
| Vurgulamak: | hava tahrikli diyafram pompası,basınçlı hava diyafram pompası |
||
Dalgıç Vakum Havalı Çift Diyaframlı Pompa 135L / Min
Kauçuk, termoplastik veya teflondiaframın pistonlu hareketinin ve diyaframın her iki tarafındaki uygun valflerin karşılıklı hareketinin bir kombinasyonunu kullanan Hava diyafram pompası ( Membran pompası, hava ile çalışan çift diyaframlı pompa (AOOD) veya pnömatik diyafram pompası olarak da bilinir) bir sıvıyı pompalamak için kelebek vanalar, kapak vanaları veya diğer herhangi bir kapatma vanaları).
Hava Tahrikli Çift Diyafram Pompası Açıklama:
Hava girişi | 1 /-4-18NPTF 1 |
Sıvı çıkışı | 1-11-1 / 2NPTF-1, Rp1-11BSP |
Sıvı Girişi | 1-11-1 /-2NPTF 1, Rp1-11BSP |
Maks. Akış | 667L / dk |
Maks. kafa | 70M |
Maks. Kendinden emişli Asansör (kuru) | 7m |
Maks. Hava basıncı | 8.3bar |
Maks. Parçacık çapı | 7mm |
Maks. Kurulum boyutu | 414 X 248 x 544mm |
Ağırlık | 24.5kg |
Gürültü @ 70psi | <70 db |
Hava Tahrikli Çift Diyaframlı Pompa Ana Avantajları
1, hava gücü kullanımı nedeniyle, akış otomatik olarak ihracat direncine göre değişti. Yüksek viskoziteli sıvı için uygundur.
2, yanıcı ve patlayıcı ortamda, pompa güvenilir ve düşük maliyetlidir, kıvılcım üretmez ve aşırı ısınmaz,
3, pompa hacmi küçük, taşınması kolay, hiçbir temel gerekli, uygun kurulum ve ekonomi. Mobil taşıma pompası olarak kullanılabilir.
4, Tehlikelerin olduğu durumlarda, aşındırıcı malzemelerin işlenmesi, diyafram pompası tamamen dışarıya ayrılabilir.
5, pompa kesme kuvveti düşüktür, ortama fiziksel etkisi küçüktür, dengesiz kimya sıvısının taşınması için kullanılabilir.
A 50 XX - XXX - X ( model seçimi)
Boru ağzı şekli: A-BSP B-NPT (F) C-Flanş
Diyafram malzemesi: 9 - Santopren H - Hytrel T - PTFE / Santopren
Top malzemesi: 9 -Santopren H - Hytre T - PTFE A - Asetal
Top koltuk malzemesi: P / K - Polipropilen / Kynoar SS - Paslanmaz Çelik
Pompa malzemesi: SS - Paslanmaz Çelik AL - Alüminyum Alaşımlı CI - Karbon Çelik P / K - Polipropilen / Kynoar
Uygulanan Maksimum Sıcaklık Limitleri (diyafram / bilye / conta malzemesi)
Asetal ································· 40 ° 40 ° A - 150 ° F (4.4 - 65.5 ° C)
Santoprene ················································· ········································· -40 ° - 225 ° F (-40 °) - 107.2 ° C) Teflon ········································································· ······························································ ···· 40 ° - 220 ° F (4.4 ° - 104 ° C) Nitril ·················································· ······························································ ···················· 10 ° - 180 ° F (-12 ° - 82 ° C) Viton ····· 10 ° - 180 ° F (-12 ° - 82 ° C) Viton ················ ······························································ ································· -40 ° - 350 ° F (-40 ° -176.6 ° C) Hytrel · ·· ··································· ······························································ ············ -20 ° -150 ° F (-12 ° - 93 ° C) Kynar ······································· ······························································ ························ 10 ° -200 ° F (-28.9 ° - 65.5 ° C), polipropilen ·········· ······························································ ································· 32 32 - 175 ° F (0-79,4 ° C)
2 " Akış diyagramı
